Hot Dip Galvanised Wire

Mild steel drawn wire passes through molten zinc and coating is done. Bright Shining and free from foreign particles. IS - 4826 IS - 280

Size		Quality	Coating (gm/mm2)
Thicker Wire	4mm to 2mm	Heavy	240 to 290
Fine Wire	1.8mm to 0.91mm	Medium	135 to 170
Size variation	±2.5% (Minimum of 0.025 mm)	Light	60 to 115
Ovality	±0.5% (Minimum of 0.025 mm)	Commercial	30 to 40
Tensile Strength
Soft	38 to 55 kgf	Hard	More than 55 kgf
Coil Size
Thicker Wire	550 mm	Fine Wire	300 mm
Coil Weight
Thicker Wire	45 to 150 kg	Fine Wire	20 to 30 kg
Packaging
Thicker Gauge	Hassian Cloth, binded four sides with wire (on demand)
Fine Sizes	PVC film wrapped and Hassian packing (on demand)
Wire Rod Raw Material ( As per IS - 7887 & IS - 2062)
Carbon	0.12 to 0.20	Phosphorous	0.05 max
Silicon	0.05 max

Stay Wire (Stranded Wire)

6 wires stranded helicably around 1 wire, in total there are seven wires stranded together. IS - 2141

Size

• 7/4 mm
• 7/3.15 mm
• 7/2.5 mm

Raw Material

Mild steel Galvanised wire (Hot Dip)

Barbed Wire

Four Barbs of 12 to 18 mm twisted around two line wires having distance of 75 mm + 12 mm, The angle of Barb is 30° - 45°.

IS - 278 (Both Grades) Size Variation ± 2.5%

Size		Length
i	12 x 12 of 2 ply 18 ft per kg. (± 5%) ( 2.5 mm x 2.5 mm of ply )	18 ft per kg. (± 5%)
	12 x 12 of ply also available
ii	12 x 14 of 2 ply ( 2.5 x 2 mm of 2 ply )	24 ft per kg. (± 5%)
	12 x 14 of 3 ply also available
iii	14 x 14 of 2 ply ( 2 mm x 2 mm of 2 ply )	32 ft per kg. (± 5%)
	14 x 14 of 3 ply also available
Barb Distance
(a) 75 mm ± 12 mm		As per requirement
(a) 150 mm ± 12 mm		As per requirement

Coil Size	300 to 400 mm
Coil Weight	30 to 45 Kg.
Packing	Unpacked
Raw-material	M.S. G.I Wire Hot Dip

Binding Wire

Size	18 SWG. AND 20 SWG
Coil Size	20 to 30 Kg.
Coil Weight	40 to 60 Kg
Quality	Soft & Black
